记录一个公司项目（uniapp原生实现异形范围选择器slider）

公司要求根据 UI 的设计实现一个如下所示的异形范围选择滑动条。

但是目前没有合适的第三方库可用，且对于拖拽事件有些手生了，所以只能亲手这个组件了，在此记录一下，顺便复习一下拖拽事件的原理。

直接上 uniapp 代码，最后实现效果就如上图所示：

<template>
  <view class="zh-slider">
    <!-- 异形图mask -->
    <view class="bar-container">
      <!-- 范围mask -->
      <view
        class="bar-cover"
        :style="`mask-image: linear-gradient(90deg, transparent 0%, transparent ${currentMinPercent}%, white ${currentMinPercent}%, white ${currentMaxPercent}%, transparent ${currentMaxPercent}%, transparent 100%);`"
      >
        <view class="bar"></view>
      </view>
    </view>
    <view class="num-val">
      <!-- 最大值和最小值 -->
      <view class="static">
        <text class="min-val">{{minVal}}</text>
        <text class="max-val">{{maxVal}}</text>
      </view>

      <!-- 滑动栏 -->
      <view
        class="handle-bar"
        @touchmove="drag"
        @touchend="dragEnd"
        @mousemove="drag"
        @mouseup="dragEnd"
      >
        <text
          data-class="current-min-val"
          class="current-min-val"
          :style="`left: ${percent1}%;`"
          @touchstart="dragStart"
          @mousedown="dragStart"
          >{{currentMinVal}}</text
        >

        <text
          data-class="current-max-val"
          class="current-max-val"
          :style="`left: ${percent2}%;`"
          @touchstart="dragStart"
          @mousedown="dragStart"
          >{{currentMaxVal}}</text
        >
      </view>
    </view>
  </view>
</template>

<script>
  export default {
    name: "zh-slider",
    props: {
      minVal: {
        type: Number,
        default: 60,
      },
      maxVal: {
        type: Number,
        default: 90,
      },
      // 单位rpx，滑动栏距离左右屏幕的距离，如果在组件外修改了这个值，则需要在此同步更改该值
      sideGapWidth: {
        type: Number,
        default: 0,
      },
    },
    data() {
      return {
        percent1: 30, // 百分比1
        percent2: 60, // 百分比2
        barActive1: false,
        barActive2: false,
        deviceWidth: 0, // 单位px，屏幕宽度
      };
    },
    computed: {
      currentMinPercent() {
        return Math.min(this.percent1, this.percent2);
      },
      currentMaxPercent() {
        return Math.max(this.percent1, this.percent2);
      },
      currentMinVal() {
        return (
          (this.percent1 / 100) * (this.maxVal - this.minVal) +
          this.minVal
        ).toFixed(0);
      },
      currentMaxVal() {
        return (
          (this.percent2 / 100) * (this.maxVal - this.minVal) +
          this.minVal
        ).toFixed(0);
      },
      // 滑动栏宽度，单位px
      handleBarContainerWidth() {
        return this.rpx2px(750 - 2 * this.sideGapWidth);
      },
    },
    mounted() {
      this.getDeviceWidth();
    },
    methods: {
      /**
       * 获取屏幕宽度
       */
      async getDeviceWidth() {
        let res = await uni.getSystemInfo();
        this.deviceWidth = res[1].windowWidth;
      },
      dragStart(e) {
        if (e.target.dataset.class === "current-min-val") {
          this.barActive1 = true;
        } else if (e.target.dataset.class === "current-max-val") {
          this.barActive2 = true;
        }
      },
      dragEnd(e) {
        this.barActive1 = this.barActive2 = false;
        let min = Math.min(this.currentMinVal, this.currentMaxVal),
          max = Math.max(this.currentMinVal, this.currentMaxVal);

        this.$emit("change", [min, max]);
      },
      drag(e) {
        if (this.barActive1 || this.barActive2) {
          e.preventDefault();
          let clientX = 0;
          if (e.type === "touchmove") {
            clientX = e.touches[0].clientX - this.rpx2px(this.sideGapWidth);
          } else {
            clientX = e.clientX - this.rpx2px(this.sideGapWidth);
          }

          if (this.barActive1) {
            if (clientX <= 0) {
              this.percent1 = 0;
            } else if (clientX >= this.handleBarContainerWidth) {
              this.percent1 = 100;
            } else {
              this.percent1 = (clientX / this.handleBarContainerWidth) * 100;
            }
          } else if (this.barActive2) {
            if (clientX <= 0) {
              this.percent2 = 0;
            } else if (clientX >= this.handleBarContainerWidth) {
              this.percent2 = 100;
            } else {
              this.percent2 = (clientX / this.handleBarContainerWidth) * 100;
            }
          }
        }
      },
      /**
       * rpx转px
       * @param {Number} rpx
       */
      rpx2px(rpx) {
        return (rpx / 750) * this.deviceWidth;
      },
      /**
       * px转rpx
       * @param {Number} px
       */
      px2rpx(px) {
        (px / this.deviceWidth) * 750;
      },
    },
  };
</script>

<style scoped lang="scss">
  .zh-slider {
    width: 700rpx;
    height: 150rpx;

    $barHeight: 55%;

    > .bar-container {
      position: relative;
      height: $barHeight;
      background-color: #eff1f1;

      // CSS 属性 mask 允许使用者通过遮罩或者裁切特定区域的图片的方式来隐藏一个元素的部分或者全部可见区域。
      // 这里本来是引用了另一个图片文件，但是为了写博客方便，就改成了base64数据
        no-repeat center/100% 100%;

      > .bar-cover {
        width: 100%;
        height: 100%;

        > .bar {
          width: 100%;
          height: 100%;
          background-image: linear-gradient(90deg, #43ad93 0%, #5beeb9 100%);
        }
      }
    }

    > .num-val {
      position: relative;
      width: 100%;
      height: calc(100% - #{$barHeight});

      > .static {
        display: flex;
        justify-content: space-between;
        align-items: center;
        width: 100%;
        height: 100%;

        > text {
          color: #9e9e9e;
        }
      }

      > .handle-bar {
        position: absolute;
        left: 0%;
        top: 0%;
        width: 100%;
        height: 100%;
        padding: 6rpx 0;
        box-sizing: border-box;

        > text {
          position: absolute;
          display: flex;
          justify-content: center;
          align-items: center;
          width: 100rpx;
          height: 60rpx;
          background-image: linear-gradient(90deg, #30ac8f 0%, #4ddebc 100%);
          border-radius: 12rpx;
          color: white;
          transform: translateX(calc(0rpx - 50%));

          &.current- {
            &min-val {
            }

            &max-val {
            }
          }
        }
      }
    }
  }
</style>
